B2430M 直流无刷电机

  • 所属分类:[全部恒驱直流无刷电机]
  • 产品简介:特征:双转向,信号功能,锁定保护,无级调速,低噪音,低电磁干扰,超长寿命3000-15000小时
  • 订购热线:400-0755-631
  • 下载资料:资料下载

    B2430M

    Output Power 输出功率: 1W~8W

    Weight 重量: 51g (Approx.)

    Brushless DC Motor-Typical Application 直流无刷电机-典型应用

    Automotive Parts: Pump    汽车部件:微型泵

    Home Application: White Goods, Small Appliance, Fanner, Electric Curtain

    家用电器:白色家电,小家电,电风扇,电动窗帘

    Medical Apparatus: Medical Pump, Blood Pressure Meter, Surgery Tools,

    Medical Stirrer, Centrifugal Machine

    医疗器械:医疗泵,血压计,手术器械,搅拌机,离心机

    Industry Equipment: Electric Valve, Portable Screwdriver, Air Pump,

    Water Pump,Vacuum Pump

    电动工具:电动阀门,手持电批,气泵,水泵,真空泵

    Business Equipment: Printer, Copier, Projector, Scanner, Cash Register

    商业设备:扫描仪,点钞机

    Personal Care: Hair Dryer, Electric Shaver, Massager

    个人护理:风筒,电动须刨,按摩器



    Model

    型号

    电压 Voltage(V)

    No Load 空载

    Rated Load 额定负载

    Stall 堵转

    Operating Range

    Rated

    Speed (rpm)

    Current (A)

    Torque (mNm)

    Speed (rpm)

    Current (A)

    Output P. (W)

    Torque (mNm)

    Current (A)

    B2430M-S01

    5-12

    6

    5380

    0.23

    3.92

    4720

    0.61

    1.94

    13.2

    1.5

    B2430M-S02

    5-12

    9

    5390

    0.11

    9.81

    3750

    0.71

    3.85

    23.2

    1.5

    B2430M-S03

    8-26

    12

    8800

    0.155

    9.81

    6330

    0.85

    6.51

    35.16

    2.66

    B2430M-S04

    8-26

    24

    4570

    0.05

    6.87

    3510

    0.18

    2.53

    29.59

    0.64

    Characteristic: CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 3000-15000hrs

    特征:双转向,信号功能,锁定保护,无级调速,低噪音,低电磁干扰,超长寿命3000-15000小时

    Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

    注意:上述规格仅针对特定客户,电压、扭矩、转速、电流、功率、输出轴的特征和尺寸等都可以按照客户的特殊要求进行调整。

    Outline Drawing 外形图:

    Usable machine screw length 2.0mm max. from motor mounting surface

    Unit: Millimeter

    Performance Curve 性能曲线:

    B2430M-S03                12V

       B2430M-S04              24V
