B1625S 外转子无刷电机

  • 所属分类:[全部恒驱直流无刷电机]
  • 产品简介:Characteristic: Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 10000-30000hrs 特征:信号功能,锁定保护,无级调速,低噪音,低电磁干扰,超长寿命10000-30000小时
  • 订购热线:400-0755-631
  • 下载资料:资料下载



    B1625S

    Outer Rotor

    Output Power 输出功率: 0.1W~3W

    Weight 重量:28 g (Approx.)

    外转子

    Brushless DC Motor-Typical Application 直流无刷电机-典型应用

    Business Equipment: Communication device, Printer, Copier, Projector, Scanner, Cash Register

    商业设备:通信设备,打印机,复印机,投影机,扫描仪,点钞机

    Home Application: White Goods, Small Appliance, Kitchen Appliance, Smart Home, Micro Actuate

    家用电器:白色家电,小家电,厨房电器,智能家居,微型致动器

    Automobile Parts: Micro Pump, Switcher   汽车部件:微型泵,切换器

    Medical Apparatus: Medical Pump, Liquid Pump, Gas Pump   医疗器械:医疗泵,液泵、气泵

    Industry Equipment: Micro Pump, Micro Valve, Instrument, Meter

    电动工具:微型泵,微型阀门,仪器仪表

    Personal Care: Skin Care, Beauty Apparatus   个人护理:皮肤护理、美容器材



    Model

    型号

    电压 Voltage(V)

    No Load 空载

    Rated Load 额定负载

    Stall 堵转

    Operating Range

    Rated

    Speed (rpm)

    Current (A)

    Torque (mNm)

    Speed (rpm)

    Current (A)

    Output P. (W)

    Torque (mNm)

    Current (A)

    B1625S-S01

    5-12

    8.5

    13343

    0.121

    1.8

    10578

    0.45

    1.99

    8.56

    0.9

    B1625S-S02

    5-12

    12

    10040

    0.049

    1.2

    7991

    0.17

    1.01

    5.88

    0.8

    B1625S-S03

    8-26

    24

    16077

    0.038

    1.7

    13399

    0.17

    2.39

    10.21

    0.2

    Characteristic: Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 10000-30000hrs   特征:信号功能,锁定保护,无级调速,低噪音,低电磁干扰,超长寿命10000-30000小时

    Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

    注意:上述规格仅针对特定客户,电压、扭矩、转速、电流、功率、输出轴的特征和尺寸等都可以按照客户的特殊要求进行调整。

    Outline Drawing 外形图:



    Unit: Millimeter

    Performance Curve 性能曲线:

    B1625S-S01                               8.5V

        B1625S-S03                            24V
